XCMG XP163 16 Tons Rubber Tire Roller

About XCMG XP163 16 Tons Rubber Tire Roller

The XCMG XP163 is equipped with a diesel engine with a power of 86KW and a rotation speed of 1800r/min. XCMG tire roller emissions meet Euro II standards, effectively reducing fuel consumption. Its compaction performance is superior. Rubber tire roller can adjust the tire ground pressure by increasing or decreasing the counterweight and changing the tire inflation pressure, thereby improving the compaction performance and expanding its use range.

XCMG XP163 16 Tons Rubber Tire Roller Specification

Model: XP163

Maximum Operating Weight: 16000kg

Water Tank Capacity: 650L

CounterWeight Total: 3600kg

Rated Power: 86kw/1800rpm

Wheel Base: 3700mm

Working Width: 2055mm

Dimensions: 4800x2536x3330mm

XCMG XP163 16 tons rubber tire roller specification only for your reference, we can manufacture other model road roller basic your request.

XCMG XP163 16 Tons Rubber Tire Roller Features

The rubber tire roller adopts a front 4-rear and 5-tire arrangement. The front wheel is a steering wheel and the rear wheel is a driving wheel. XCMG rubber tire roller adopts a fully hydraulic steering system, air-assisted hydraulic brakes and a multi speed transmission system, which makes it travel faster, operate more maneuverably and flexibly, and transfer between construction sites more conveniently and quickly.The XCMG XP163 tire roller also adopts a front wheel swing mechanism. This mechanism allows the roller to ensure uniform wheel pressure contact when operating on uneven ground, and evenly compact the uneven areas of the compacted material.

XCMG XP163 16 Tons Rubber Tire Roller Advantage

The XCMG XP163 is equipped with an emergency braking system and a parking braking system. These two braking systems can have interlocking functions. Emergency braking adopts a dual circuit air circuit control braking system, which effectively improves braking reliability, shortens the braking distance of the entire vehicle, and enables faster braking response. This tire press is equipped with a sprinkler system that sprays water on the tire surface to prevent asphalt from adhering to the tire. This XCMG tire roller can be equipped with an optional intermittent water sprinkler function.
